Multiswitch VLAN with Router-on-a-Stick

Build a real-world VLAN setup across two switches and connect them to a router using trunk links and sub-interfaces.

Certificationccie
Leveladvanced
CategorySwitching
Estimated Time~60 minutes
PlatformDynamips Cloud
Creator
AliAli Mansouri
Lab Topology Preview

What You'll Learn

  • Configure VLANs and trunk links
  • Implement Router-on-a-Stick for Inter-VLAN routing
  • Design segmented networks with management and voice VLANs

Scenario Background

You've just joined the IT team of a growing mid-sized company. Departments are complaining about lack of segmentation and unstable voice calls. Everything is in VLAN 1. Your task is to redesign the network: segment devices, add trunk links, and enable inter-VLAN routing.
